# LED Driver, 16.8 W, 24 VDC, 700 mA, Constant Current

> 🔍 **Component Stock & Purchasing**: Search live inventory and purchase electronic components directly at [novapart.co](https://novapart.co). For custom volume orders or hard-to-find parts, [request a free quote](https://novapart.co/quote/).

![Product image](https://novapart.co/image/farnell:3390981/)

**URL**: https://novapart.co/products/LED-DR-700-20/led-driver-168-w-24-vdc-700-ma-constant-current
**SKU**: LED-DR-700-20
**Manufacturer**: POWERPAX
**Category**: LED Lighting Components || LED Power Supplies || AC / DC LED Power Supplies
**Price**: €14.2200
**Stock**: 10+

## Specifications

| Parameter | Value |
|---|---|
| Svhc | To Be Advised |
| Product Range | - |
| Output Current | 700mA |
| Led Driver Mode | Constant Current |
| Output Power Max | 16.8W |
| Input Voltage Max | 230V |
| Input Voltage Min | - |
| Output Voltage Max | 24VDC |
| Power Supply Applications | - |

## Datasheet

📄 [Download PDF](https://novapart.co/datasheet/farnell:3390981/)

## **CONSTANT CURRENT LED DRIVER**

## **20WATT**

## POWERPAX: LED-DR-700-20

## **Features:**

- Input Voltage 180-264vac

- IP20 Rated

- Class II

- Compact Plastic Low Profile enclosure

- 1 Year Warranty

## **Description:**

The Range of 20 Watt Constant Current LED Drivers are housed in a compact light weight high quality IP20 plastic enclosure with covered input & output terminals suitable for general Indoor LED applications.

|Specification|Specification|
|---|---|
|Part Number|LED-DR-700-20|
|Output Voltage Range|14-29Vdc|
|Output Current Range|700mA|
|Rated Power|20 Watt|
|Dimensions|154 x 50 x 14.5 mm|
|Input Voltage Range|180-264VAC|
|Input Voltage Frequency|50Hz|
|Inrush Current|<70A|
|Input power|<24.5W|
|Efficiency|≥82%|
|Power Consumption Without Load|<0.5W|
|Over Load Protection|Ta, 0.94-1.06 times of input voltage, 1.2 times of rated<br>power|
|Short Circuit Protection|Ta, 0.94-1.06 times of input voltage|
|Automatically Restart|Yes|
|Working Temperature|-20°C ~ +45°C|
|Relative Humidity|45% ~ 85%|
|MTBF|30000hr|
|EMC emission|EN55015|
|EMC Immunity|EN6100-3-2, EN61547|
|Safety Standards|IEC61347-1, IEC61347-2-13|



## General Note

TT Electronics IoT Solutions Ltd Tofts Farm East, Brenda Road, Hartlepool, TS25 2BQ, UK

TT Electronics reserves the right to make changes in product specification without notice or liability.  All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.

t: +44 (0) 1429 852 500

ISS.3   17/07/2020  Page: 1

© TT Electronics plc

## **CONSTANT CURRENT LED DRIVER**

## **20WATT**

## POWERPAX: LED-DR-700-20

## **Diagrams**

## **Wiring Diagram**

TT Electronics IoT Solutions Ltd Tofts Farm East, Brenda Road, Hartlepool, TS25 2BQ, UK t: +44 (0) 1429 852 500

General Note

TT Electronics reserves the right to make changes in product specification without notice or liability.  All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.

ISS.3   17/07/2020  Page: 2

© TT Electronics plc
