EEUFR1J101B

Electrolytic Capacitor, 100 µF, 63 V, ± 20%, Radial Leaded, 6000 hours @ 105°C, Polar

⚠️ Reference pricing provided. In case of supply shortages, we will connect you with our trusted procurement partners to ensure your project's continuity.

Manufacturer: PANASONIC
Product type: Leaded Aluminium Electrolytic Capacitors
Capacitance:100µF; Voltage Rating:63V; Product Range:FR Series; Capacitance Tolerance:± 20%; Capacitor Terminals:Radial Leaded; Diameter:10mm; Lead Spacing:5mm; Height:12.5mm; Operating Temperature
ESR: 0.063ohm
SVHC: No SVHC (04-Feb-2026)
Polarity: Polar
Capacitance: 100µF
Voltage(DC): 63V
Lead Spacing: 5mm
Product Range: FR Series
Product Width: -
Qualification: -
Product Height: 12.5mm
Product Length: -
Ripple Current: 761mA
Product Diameter: 10mm
Capacitor Terminals: Radial Leaded
Capacitance Tolerance: ± 20%
Lifetime @ Temperature: 6000 hours @ 105°C
Capacitor Case / Package: Radial Leaded
Operating Temperature Max: 105°C
Operating Temperature Min: -40°C

Delivery and price
Units per pack	500
Price	0.272 €
Current stock	1000+
Lead time	30 days

Datasheet

**Aluminum Electrolytic Capacitors (Radial Lead Type)**

## **Radial Lead Type**

## Series : **FR** Type : **A**

## **Features**

- Low ESR (Same as FM Series)

## Po **Country of origin**

   - Malaysia

- Endurance : 105 °C 5000 h to 10000 h

- RoHS compliant

## **Attention**

- Not applicable for automotive

## Po **Specifi cations**

|Category temperature range|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|–40 °C to +105 °C|
|---|---|---|---|---|---|---|---|---|---|---|
|Rated voltage range|6.3 V.DC to 100 V.DC||||||||||
|Capacitance range|4.7 µF to 8200 µF||||||||||
|Capacitance tolerance|±20 % (120 Hz/+20 °C)||||||||||
|Leakage current|I<0.01 CV(µA)After 2 minutes<br>~~ns~~<br>~~neGD~~<br>~~I~~||||||||||
|Dissipation factor<br>(tand)<br>~~En~~<br>~~s~~|V.DC<br>~~En~~|6.3<br>~~En~~<br>~~ns~~|10<br>~~En~~<br>~~ne~~<br>~~ns~~|16<br>~~En~~<br>~~GD~~<br>~~Gn~~|25<br>~~En~~<br>~~GD~~<br>nD|35<br>~~En~~|50<br>~~En~~<br>~~I~~|63<br>~~En~~<br>~~I~~|100<br>~~En~~|(120 Hz/+20 °C)|
||tand<br>~~s~~|0.22<br>~~ns~~<br>~~s~~|0.19<br>~~ne~~<br>~~s~~<br>~~ns~~|0.16<br>~~GD~~<br>~~ss~~<br>~~Gn~~|0.14<br>~~GD~~<br>~~s~~<br>nD|0.12<br>~~s~~|0.10<br>~~I~~<br>~~s~~|0.09<br>~~I~~<br>~~s~~|0.08<br>~~s~~||
||Add 0.02 per 1000 µF for products of 1000 µF or more.<br>~~nsGn~~ nD||||||||||
|Endurance<br>~~FY~~<br>~~Ps~~<br>fF|After following life test with DC voltage and +105 °C±2 °C ripple current value applied. (The sum<br>of DC and ripple peak voltage shall not exceed the rated working voltage) when the capacitors<br>are restored to 20 °C, the capacitors shall meet the limits specifi ed below.<br>Duration<br>05×11/06.3×11.2 : 5000 hours<br>08×11.5/010×12.5 : 6000 hours (✽Only EEUFR1V331U (010×12.5) 5000 hours)<br>08×15/010×16 : 8000 hours,08×20 : 9000 hours<br>010×20 to010×25/ 012.5×20 to012.5×35/016×20 to016×25 : 10000 hours||||||||||
||Capacitance change <br>~~FY~~|Within ±25 % of the initial value (6.3 V.DC to 10 V.DC : ±30 %)|||||||||
||tand<br>~~Ps~~<br>fF|<200 %of the initial limit|||||||||
||DC leakage current<br>fF|Within the initial limit|||||||||
|Shelf life<br>fF|After storage for 1000 hours at +105 °C±2 °C with no voltage applied and then being stabilized<br>at +20 °C, capacitors shall meet the limits specifi ed in Endurance. (With voltage treatment)<br>fF||||||||||



## ~~PO~~ **Frequency correction factor for ripple current**

|Rated voltage (V.DC)|Capacitance (µF)|Frequency (Hz)|Frequency (Hz)|Frequency (Hz)|Frequency (Hz)|Frequency (Hz)|
|---|---|---|---|---|---|---|
|||60|120|1 k|10 k|100 k|
|6.3 to 100|4.7 to<br>33|0.45|0.55|0.75|0.90|1.00|
||47<br>to<br>330|0.60|0.70|0.85|0.95|1.00|
||390<br>to<br>1000|0.65|0.75|0.90|0.98|1.00|
||1200<br>to<br>8200|0.75|0.80|0.95|1.00|1.00|



## **Dimensions**

|Pressure relief<br>06.3<|||Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|Sleeve<br>14 min.<br>3 min.<br>L✽<br>+<br>–<br><08<br>0D±0.5<br>F±0.5<br>fd±0.05<br>~~JES~~<br>~~ad ~~ee|010<<br>0D±0.5|010<<br>0D±0.5|010<<br>0D±0.5||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
||||✽L<16 : L±1.5||||||||||||||||||||||||
||||L>20 : L±2.0|||||||||||||||||||||||(Unit : mm)|
|0D|||5|||||6.3|||||8||10||||||12.5|||||16|
|L|||—|||||—|||||—||—|||12.5 to 25|||12.5 to 25||30 to 35|30 to 35||—|
|0d|||0.5|||||0.5|||||0.6||0.6|||||0.6||||0.8||0.8|
|F|||2.0|||||2.5|||||3.5||5.0||||||5.0|||||7.5|



Design and specifications are each subject to change without notice.  Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately.

07 Mar. 2016

**Aluminum Electrolytic Capacitors (Radial Lead Type)**

## **Case size/ Impedance/ Ripple current**

**==> picture [491 x 69] intentionally omitted <==**

**----- Start of picture text -----**<br>
Rated voltage<br>6.3 V.DC to 35 V.DC 50 V.DC<br>(V.DC)<br>Case size Imped ance Ripple current Imped ance Ripple current<br>(mm) (Ω/100 kHz) (mA r.m.s./100 kHz) (Ω/100 kHz) (mA r.m.s./100 kHz)<br>(0D×L)<br>+20 °C –10 °C +105 °C +20 °C –10 °C +105 °C<br>**----- End of picture text -----**<br>


|Rated voltage<br>(V.DC)<br>Case size<br>(mm)<br>(0D×L)|6.3 V.DC to 35 V.DC|6.3 V.DC to 35 V.DC|6.3 V.DC to 35 V.DC|50 V.DC|50 V.DC|50 V.DC|
|---|---|---|---|---|---|---|
||Imped ance<br>(Ω/100 kHz)||Ripple current<br>(mA r.m.s./100 kHz)|Imped ance<br>(Ω/100 kHz)||Ripple current<br>(mA r.m.s./100 kHz)|
||+20 °C|–10 °C|+105 °C|+20 °C|–10 °C|+105 °C|
||||||||
|5<br>×11|0.300|1.000|280|0.340|1.130|250|
|6.3×11.2|0.130|0.430|455|0.140|0.460|405|
|8<br>×11.5|0.056|0.168|950|0.061|0.183|870|
|8<br>×15|0.041|0.123|1240|0.045|0.135|1140|
|8<br>×20|0.030|0.090|1560|0.033|0.099|1430|
|10<br>×12.5|0.043|0.114|1290|0.042|0.126|1170|
|10<br>×16|0.028|0.078|1790|0.030|0.090|1650|
|10<br>×20|0.020|0.057|2180|0.023|0.069|1890|
|10<br>×25|0.018|0.054|2470|0.022|0.066|2150|
|12.5×20|0.018|0.045|2600|0.022|0.055|2260|
|12.5×25|0.015|0.038|3190|0.018|0.045|2660|
|12.5×30|0.013|0.033|3630|0.016|0.040|3160|
|12.5×35|0.012|0.030|3750|0.014|0.035|3270|
|16<br>×20|0.017|0.043|3300|0.019|0.048|2870|
|16<br>×25|0.014|0.035|3820|0.016|0.040|3320|



**==> picture [287 x 373] intentionally omitted <==**

**----- Start of picture text -----**<br>
Rated voltage<br>63 V.DC<br>(V.DC)<br>Case size Imped ance Ripple current<br>(mm) (Ω/100 kHz) (mA r.m.s./100 kHz)<br>(0D×L)<br>+20 °C –10 °C +105 °C<br> 5  ×  11 0.510 2.040 175<br> 6.3  ×  11.2 0.210 0.840 284<br> 8  ×  11.5 0.092 0.368 566<br> 8  ×  15 0.068 0.272 741<br> 8  ×  20 0.050 0.200 930<br>10  ×  12.5 0.063 0.252 761<br>10  ×  16 0.045 0.180 1073<br>10  ×  20 0.035 0.140 1229<br>10  ×  25 0.033 0.132 1500<br>12.5  ×  20 0.033 0.125 1582<br>12.5  ×  25 0.027 0.092 1995<br>12.5  ×  30 0.024 0.082 2528<br>12.5  ×  35 0.021 0.071 2780<br>16  ×  20 0.029 0.093 2153<br>16  ×  25 0.024 0.074 2988<br>Rated voltage<br>100 V.DC<br>(V.DC)<br>Case size Imped ance Ripple current<br>(mm) (Ω/100 kHz) (mA r.m.s./100 kHz)<br>(0D×L)<br>+20 °C –10 °C +105 °C<br>10  ×  20 0.084 0.336 1500<br>**----- End of picture text -----**<br>


Design and specifications are each subject to change without notice.  Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately.

07 Mar. 2016

**Aluminum Electrolytic Capacitors (Radial Lead Type)**

## **Characteristics list**

**==> picture [491 x 69] intentionally omitted <==**

**----- Start of picture text -----**<br>
Case size (mm) Specifi cation Lead length (mm) Min. Packaging Q'ty<br>Rated Cap. Ripple Impedance Lead space<br>voltage (±20 %) current (100 kHz) Endurance Lead Part No. Straight Taping<br>(V.DC) (µF) 0D L (100 kHz)(+105 °C) (+20 °C)(Ω) (hours) dia.0d Straight [Taping] ✽B Taping✽H (pcs)leads (pcs)<br>(mA r.m.s.)<br>**----- End of picture text -----**<br>


|Rated<br>voltage<br>(V.DC)|Cap.<br>(±20 %)<br>(µF)|Case size (mm)|Case size (mm)|Specif cation|Specif cation|Specif cation|Lead length (mm)|Lead length (mm)|Lead length (mm)|Lead length (mm)|Part No.|Min. Packaging Q'ty|Min. Packaging Q'ty|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|||0D|L|Ripple<br>current<br>(100 kHz)<br>(+105 °C)<br>(mA r.m.s.)|Impedance<br>(100 kHz)<br>(+20 °C)<br>(Ω)|Endurance<br>(hours)|Lead<br>dia.<br>0d|Lead space||||Straight<br>leads<br>(pcs)|Taping<br>(pcs)|
|||||||||Straight|Taping<br>✽B|Taping<br>✽H||||
|||||||||||||||
|6.3|150|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR0J151( )|200|2000|
||220|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR0J221( )|200|2000|
||330|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR0J331( )|200|2000|
||470|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR0J471( )|200|2000|
||820|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR0J821( )|200|1000|
||1000|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR0J102( )|200|1000|
||1200|<br>8|15|1240|0.041|8000|0.6|3.5|5.0||EEUFR0J122L( )|200|1000|
|||<br>10|12.5|1290|0.043|6000|0.6|5.0|5.0||EEUFR0J122( )|200|500|
||1500|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||EEUFR0J152L( )|200|1000|
||1800|10|16|1790|0.028|8000|0.6|5.0|5.0||EEUFR0J182( )|200|500|
||2200|10|20|2180|0.020|10000|0.6|5.0|5.0||EEUFR0J222( )|200|500|
||2700|10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR0J272L( )|200|500|
||3300|10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR0J332L( )|200|500|
||3900|12.5|20|2600|0.018|10000|0.6|5.0|5.0||EEUFR0J392( )|200|500|
||4700|12.5|25|3190|0.015|10000|0.6|5.0|5.0||EEUFR0J472( )|200|500|
||5600|12.5|30|3630|0.013|10000|0.8|5.0|||EEUFR0J562L|100||
||6800|12.5|35|3750|0.012|10000|0.8|5.0|||EEUFR0J682L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR0J682S( )|100|250|
||8200|16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR0J822( )|100|250|
|10|100|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1A101( )|200|2000|
||150|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1A151( )|200|2000|
||220|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR1A221( )|200|2000|
||270|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR1A271( )|200|2000|
||470|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR1A471( )|200|1000|
||680|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR1A681( )|200|1000|
||820|10|12.5|1290|0.043|6000|0.6|5.0|5.0||EEUFR1A821( )|200|500|
||1000|10|16|1790|0.028|8000|0.6|5.0|5.0||EEUFR1A102( )|200|500|
|||<br>8|15|1240|0.041|8000|0.6|3.5|5.0||EEUFR1A102L( )|200|1000|
||1500|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||EEUFR1A152L( )|200|1000|
|||<br>10|16|1790|0.028|8000|0.6|5.0|5.0||EEUFR1A152( )|200|500|
||1800|10|20|2180|0.020|10000|0.6|5.0|5.0||EEUFR1A182( )|200|500|
||2200|10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR1A222L( )|200|500|
||3300|12.5|20|2600|0.018|10000|0.6|5.0|5.0||EEUFR1A332( )|200|500|
||3900|12.5|25|3190|0.015|10000|0.6|5.0|5.0||EEUFR1A392( )|200|500|
||4700|12.5|30|3630|0.013|10000|0.8|5.0|||EEUFR1A472L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1A472S( )|100|250|
||5600|12.5|35|3750|0.012|10000|0.8|5.0|||EEUFR1A562L|100||
||6800|12.5|35|3750|0.012|10000|0.8|5.0|||EEUFR1A682L|100||
|||<br>16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR1A682( )|100|250|



· When requesting taped product, please put the letter "B" or "H" be tween the "( )". Lead wire pitch ✽B=5 mm, 7.5 mm, H=2.5 mm.

· Please refer to the page of “Taping dimensions”.

Design and specifications are each subject to change without notice.  Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately.

07 Mar. 2016

**Aluminum Electrolytic Capacitors (Radial Lead Type)**

## **Characteristics list**

**==> picture [491 x 69] intentionally omitted <==**

**----- Start of picture text -----**<br>
Case size (mm) Specifi cation Lead length (mm) Min. Packaging Q'ty<br>Rated Cap. Ripple Impedance Lead space<br>voltage (±20 %) current (100 kHz) Endurance Lead Part No. Straight Taping<br>(V.DC) (µF) 0D L (100 kHz)(+105 °C) (+20 °C)(Ω) (hours) dia.0d Straight [Taping] ✽B Taping✽H (pcs)leads (pcs)<br>(mA r.m.s.)<br>**----- End of picture text -----**<br>


|Rated<br>voltage<br>(V.DC)|Cap.<br>(±20 %)<br>(µF)|Case size (mm)|Case size (mm)|Specif cation|Specif cation|Specif cation|Lead length (mm)|Lead length (mm)|Lead length (mm)|Lead length (mm)|Part No.|Min. Packaging Q'ty|Min. Packaging Q'ty|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|||0D|L|Ripple<br>current<br>(100 kHz)<br>(+105 °C)<br>(mA r.m.s.)|Impedance<br>(100 kHz)<br>(+20 °C)<br>(Ω)|Endurance<br>(hours)|Lead<br>dia.<br>0d|Lead space||||Straight<br>leads<br>(pcs)|Taping<br>(pcs)|
|||||||||Straight|Taping<br>✽B|Taping<br>✽H||||
|||||||||||||||
|16|68|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1C680( )|200|2000|
||100|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1C101( )|200|2000|
||120|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR1C121( )|200|2000|
||220|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR1C221( )|200|2000|
||470|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR1C471( )|200|1000|
||680|<br>8|15|1240|0.041|8000|0.6|3.5|5.0||EEUFR1C681L( )|200|1000|
|||<br>10|12.5|1290|0.043|6000|0.6|5.0|5.0||EEUFR1C681( )|200|500|
||1000|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||EEUFR1C102L( )|200|1000|
|||<br>10|16|1790|0.028|8000|0.6|5.0|5.0||EEUFR1C102( )|200|500|
||1500|10|20|2180|0.020|10000|0.6|5.0|5.0||EEUFR1C152( )|200|500|
|||<br>10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR1C152L( )|200|500|
||1800|10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR1C182L( )|200|500|
||2200|12.5|20|2600|0.018|10000|0.6|5.0|5.0||EEUFR1C222( )|200|500|
||2700|12.5|25|3190|0.015|10000|0.6|5.0|5.0||EEUFR1C272( )|200|500|
||3300|12.5|30|3630|0.013|10000|0.8|5.0|||EEUFR1C332L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1C332S( )|100|250|
||3900|12.5|35|3750|0.012|10000|0.8|5.0|||EEUFR1C392L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1C392S( )|100|250|
||4700|12.5|35|3750|0.012|10000|0.8|5.0|||EEUFR1C472L|100||
|||<br>16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR1C472( )|100|250|
||5600|16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR1C562( )|100|250|
|25|47|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1E470( )|200|2000|
||68|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1E680( )|200|2000|
||100|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR1E101( )|200|2000|
||150|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|EEUFR1E151( )|200|2000|
||220|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR1E221( )|200|1000|
||330|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||EEUFR1E331( )|200|1000|
||390|<br>8|15|1240|0.041|8000|0.6|3.5|5.0||EEUFR1E391L( )|200|1000|
||470|8|15|1240|0.041|8000|0.6|3.5|5.0||EEUFR1E471Y( )|200|1000|
|||8|20|1560|0.030|9000|0.6|3.5|5.0||EEUFR1E471L( )|200|1000|
|||10|12.5|1290|0.043|6000|0.6|5.0|5.0||EEUFR1E471( )|200|500|
||560|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||EEUFR1E561L( )|200|1000|
||680|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||EEUFR1E681L( )|200|1000|
|||<br>10|16|1790|0.028|8000|0.6|5.0|5.0||EEUFR1E681( )|200|500|
||820|10|20|2180|0.020|10000|0.6|5.0|5.0||EEUFR1E821( )|200|500|
||1000|10|20|2180|0.020|10000|0.6|5.0|5.0||EEUFR1E102( )|200|500|
|||<br>10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR1E102L( )|200|500|
||1200|10|25|2470|0.018|10000|0.6|5.0|5.0||EEUFR1E122L( )|200|500|
||1500|12.5|20|2600|0.018|10000|0.6|5.0|5.0||EEUFR1E152( )|200|500|
||1800|12.5|25|3190|0.015|10000|0.6|5.0|5.0||EEUFR1E182( )|200|500|
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1E182S( )|100|250|
||2200|12.5|30|3630|0.013|10000|0.8|5.0|||EEUFR1E222L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1E222S( )|100|250|
||2700|12.5|35|3750|0.012|10000|0.8|5.0|||EEUFR1E272L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1E272S( )|100|250|
||3300|16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR1E332( )|100|250|



· When requesting taped product, please put the letter "B" or "H" be tween the "( )". Lead wire pitch ✽B=5 mm, 7.5 mm, H=2.5 mm.

· Please refer to the page of “Taping dimensions”.

Design and specifications are each subject to change without notice.  Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately.

07 Mar. 2016

**Aluminum Electrolytic Capacitors (Radial Lead Type)**

## **Characteristics list**

**==> picture [491 x 77] intentionally omitted <==**

**----- Start of picture text -----**<br>
Case size (mm) Specifi cation Lead length (mm) Min. Packaging Q'ty<br>Rated Cap. Ripple Impedance Lead space<br>voltage (±20 %) current (100 kHz) Endurance Lead Part No. Straight Taping<br>(V.DC) (µF) 0D L (100 kHz)(+105 °C) (+20 °C)(Ω) (hours) dia.0d Straight [Taping] ✽B Taping✽H (pcs)leads (pcs)<br>(mA r.m.s.)<br>33 5  11 280 0.300 5000 0.5 2.0 5.0 2.5 EEUFR1V330( ) 200 2000<br>**----- End of picture text -----**<br>


|Rated<br>voltage<br>(V.DC)|Cap.<br>(±20 %)<br>(µF)|Case size (mm)|Case size (mm)|Specif cation|Specif cation|Specif cation|Lead length (mm)|Lead length (mm)|Lead length (mm)|Lead length (mm)|Part No.|Min. Packaging Q'ty|Min. Packaging Q'ty|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|||0D|L|Ripple<br>current<br>(100 kHz)<br>(+105 °C)<br>(mA r.m.s.)|Impedance<br>(100 kHz)<br>(+20 °C)<br>(Ω)|Endurance<br>(hours)|Lead<br>dia.<br>0d|Lead space||||Straight<br>leads<br>(pcs)|Taping<br>(pcs)|
|||||||||Straight|Taping<br>✽B|Taping<br>✽H||||
||33|<br>5|11|280|0.300|5000|0.5|2.0|5.0|2.5|EEUFR1V330( )|200|2000|
|35|68|<br>6.3|11.2|455|0.130|5000|0.5|2.5|5.0|2.5|<br>EEUFR1V680( )|200|2000|
||100|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||<br>EEUFR1V101( )|200|1000|
||180|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||<br>EEUFR1V181( )|200|1000|
||220|<br>8|11.5|950|0.056|6000|0.6|3.5|5.0||<br>EEUFR1V221( )|200|1000|
||270|<br>8|15|1240|0.041|8000|0.6|3.5|5.0||<br>EEUFR1V271L( )|200|1000|
|||<br>10|12.5|1290|0.043|6000|0.6|5.0|5.0||<br>EEUFR1V271( )|200|500|
||330|10|12.5|1330|0.043|5000|0.6|5.0|5.0||<br>EEUFR1V331U( )|200|500|
||390|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||<br>EEUFR1V391L( )|200|1000|
||470|<br>8|20|1560|0.030|9000|0.6|3.5|5.0||<br>EEUFR1V471L( )|200|1000|
|||<br>10|16|1790|0.028|8000|0.6|5.0|5.0||<br>EEUFR1V471( )|200|500|
||560|10|20|2180|0.020|10000|0.6|5.0|5.0||<br>EEUFR1V561( )|200|500|
||680|10|20|2180|0.020|10000|0.6|5.0|5.0||<br>EEUFR1V681( )|200|500|
|||<br>10|25|2470|0.018|10000|0.6|5.0|5.0||<br>EEUFR1V681L( )|200|500|
||820|10|25|2470|0.018|10000|0.6|5.0|5.0||<br>EEUFR1V821L( )|200|500|
||1000|12.5|20|2600|0.018|10000|0.6|5.0|5.0||<br>EEUFR1V102( )|200|500|
||1200|12.5|25|3190|0.015|10000|0.6|5.0|5.0||<br>EEUFR1V122( )|200|500|
||1500|12.5|30|3630|0.013|10000|0.8|5.0|||<br>EEUFR1V152L|100||
|||<br>16|20|3300|0.017|10000|0.8|7.5|7.5||EEUFR1V152S( )|100|250|
||1800|12.5|35|3750|0.012|10000|0.8|5.0|||<br>EEUFR1V182L|100||
|||<br>16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR1V182( )|100|250|
||2200|12.5|35|3750|0.012|10000|0.8|5.0|||<br>EEUFR1V222L|100||
|||<br>16|25|3820|0.014|10000|0.8|7.5|7.5||EEUFR1V222( )|100|250|
|50|4.7|<br>5|11|185|0.620|5000|0.5|2.0|5.0|2.5|<br>EEUFR1H4R7( )|200|2000|
||10|<br>5|11|250|0.340|5000|0.5|2.0|5.0|2.5|<br>EEUFR1H100( )|200|2000|
||22|<br>5|11|250|0.340|5000|0.5|2.0|5.0|2.5|<br>EEUFR1H220( )|200|2000|
||47|<br>6.3|11.2|405|0.140|5000|0.5|2.5|5.0||<br>EEUFR1H470( )|200|2000|
||56|<br>6.3|11.2|405|0.140|5000|0.5|2.5|5.0|2.5|<br>EEUFR1H560( )|200|2000|
||100|<br>8|11.5|870|0.061|6000|0.6|3.5|5.0||<br>EEUFR1H101( )|200|1000|
||120|<br>8|15|1140|0.045|8000|0.6|3.5|5.0||<br>EEUFR1H121L( )|200|1000|
||150|10|12.5|1170|0.042|6000|0.6|5.0|5.0||<br>EEUFR1H151( )|200|500|
||180|<br>8|20|1430|0.033|9000|0.6|3.5|5.0||<br>EEUFR1H181L( )|200|1000|
||220|10|16|1650|0.030|8000|0.6|5.0|5.0||<br>EEUFR1H221( )|200|500|
||270|10|20|1890|0.023|10000|0.6|5.0|5.0||<br>EEUFR1H271( )|200|500|
||330|10|25|2150|0.022|10000|0.6|5.0|5.0||<br>EEUFR1H331L( )|200|500|
||470|12.5|20|2260|0.022|10000|0.6|5.0|5.0||<br>EEUFR1H471( )|200|500|
||560|12.5|25|2660|0.018|10000|0.6|5.0|5.0||<br>EEUFR1H561( )|200|500|
||680|12.5|30|3160|0.016|10000|0.8|5.0|||<br>EEUFR1H681L|100||
||820|12.5|35|3270|0.014|10000|0.8|5.0|||EEUFR1H821L|100||
|||<br>16|20|2870|0.019|10000|0.8|7.5|7.5||EEUFR1H821S( )|100|250|
||1000|16|25|3320|0.016|10000|0.8|7.5|7.5||<br>EEUFR1H102( )|100|250|
|63|18|<br>5|11|175|0.510|5000|0.5|2.0|5.0|2.5|<br>EEUFR1J180( )|200|2000|
||47|<br>6.3|11.2|284|0.210|5000|0.5|2.5|5.0|2.5|<br>EEUFR1J470( )|200|2000|
||82|<br>8|11.5|566|0.092|6000|0.6|3.5|5.0||<br>EEUFR1J820( )|200|1000|
||100|<br>8|15|741|0.068|8000|0.6|3.5|5.0||<br>EEUFR1J101L( )|200|1000|
|||<br>10|12.5|761|0.063|6000|0.6|5.0|5.0||<br>EEUFR1J101( )|200|500|
||120|<br>8|20|930|0.050|9000|0.6|3.5|5.0||<br>EEUFR1J121L( )|200|1000|
|||<br>10|16|1073|0.045|8000|0.6|5.0|5.0||<br>EEUFR1J121( )|200|500|
||150|<br>8|20|930|0.050|9000|0.6|3.5|5.0||<br>EEUFR1J151L( )|200|1000|
|||<br>10|16|1073|0.045|8000|0.6|5.0|5.0||<br>EEUFR1J151( )|200|500|
||180|10|20|1229|0.035|10000|0.6|5.0|5.0||<br>EEUFR1J181( )|200|500|
||220|10|25|1500|0.033|10000|0.6|5.0|5.0||<br>EEUFR1J221L( )|200|500|
||270|10|20|1229|0.035|10000|0.6|5.0|5.0||<br>EEUFR1J271U( )|200|500|
|||10|25|1500|0.033|10000|0.6|5.0|5.0||<br>EEUFR1J271L( )|200|500|
|||12.5|20|1582|0.033|10000|0.6|5.0|5.0||<br>EEUFR1J271( )|200|500|
||330|12.5|20|1582|0.033|10000|0.6|5.0|5.0||<br>EEUFR1J331( )|200|500|
||390|12.5|25|1995|0.027|10000|0.6|5.0|5.0||<br>EEUFR1J391( )|200|500|
||470|12.5|25|1995|0.027|10000|0.6|5.0|5.0||<br>EEUFR1J471( )|200|500|
||560|12.5|30|2528|0.024|10000|0.8|5.0|||<br>EEUFR1J561L|100||
|||<br>16|20|2153|0.029|10000|0.8|7.5|7.5||EEUFR1J561S( )|100|250|
||680|12.5|35|2780|0.021|10000|0.8|5.0|||<br>EEUFR1J681L|100||
||820|16|25|2988|0.024|10000|0.8|7.5|7.5||EEUFR1J821( )|100|250|
|100|100|10|20|1500|0.084|10000|0.6|5.0|5.0||<br>EEUFR2A101( )|200|500|
|· When requesting taped product, please put the letter "B" or "H" be tween the "( )". Lead wire pitch✽B=5 mm, 7.5 mm, H=2.5 mm.<br>· Please refer to the page of “Taping dimensions”.||||||||||||||



Design and specifications are each subject to change without notice.  Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately.

07 Mar. 2016

~~es~~

Guidelines and precautions regarding the technical information and use of our products described in this online catalog.

m= If you want to use our products described in this online catalog for applications requiring special qualities or reliability, or for applications where the failure or malfunction of the products may directly jeopardize human life or potentially cause personal injury (e.g. aircraft and aerospace equipment, traffic and transportation equipment, combustion equipment, medical equipment, accident prevention, anti-crime equipment, and/or safety equipment), it is necessary to verify whether the specifications of our products fit to such applications. Please ensure that you will ask and check with our inquiry desk as to whether the specifications of our products fit to such applications use before you use our products.

m The quality and performance of our products as described in this online catalog only apply to our products when used in isolation. Therefore, please ensure you evaluate and verify our products under the specific circumstances in which our products are assembled in your own products and in which our products will actually be used.

m@ If you use our products in equipment that requires a high degree of reliability, regardless of the application, it is recommended that you set up protection circuits and redundancy circuits in order to ensure safety of your equipment.

m The products and product specifications described in this online catalog are subject to change for improvement without prior notice. Therefore, please be sure to request and confirm the latest product specifications which explain the specifications of our products in detail, before you finalize the design of your applications, purchase, or use our products.

m@ The technical information in this online catalog provides examples of our products' typical operations and application circuits. We do not guarantee the non-infringement of third party's intellectual property rights and we do not grant any license, right, or interest in our intellectual property.

m@ If any of our products, product specifications and/or technical information in this online catalog is to be exported or provided to non-residents, the laws and regulations of the exporting country, especially with regard to security and export control, shall be observed.

<Regarding the Certificate of Compliance with the EU RoHS Directive/REACH Regulations>

m The switchover date for compliance with the RoHS Directive/REACH Regulations varies depending on the part number or series of our products.

m When you use the inventory of our products for which it is unclear whether those products are compliant with the RoHS Directive/REACH Regulation, please select "Sales Inquiry" in the website inquiry form and contact us.

We do not take any responsibility for the use of our products outside the scope of the specifications, descriptions, guidelines and precautions described in this online catalog.

01-Apr-19

Updated at June 5, 2026

Panasonic Industry is a global leader in the design and manufacture of high-quality electronic components. Renowned for a commitment to continuous innovation, the company provides the essential building blocks that empower modern engineering. From industrial automation to consumer electronics, Panasonic's components are trusted worldwide for their outstanding reliability, efficiency, and long-term performance. The extensive portfolio is anchored by a massive selection of passive components, featuring an industry-leading range of aluminium electrolytic, film, and polymer capacitors. Alongside these advanced capacitance solutions, engineers rely on Panasonic's robust power inductors and a highly versatile array of electromechanical devices, including solid-state, power, and signal relays engineered to excel in demanding environments. Beyond core passives and switching solutions, the offering encompasses critical circuit protection devices such as TVS varistors and NTC thermistors, as well as sophisticated thermal management materials. Panasonic also delivers precision light and motion sensors, highly reliable batteries, and advanced Bluetooth and WLAN connectivity modules, providing a comprehensive ecosystem of components to support next-generation technological design.

About Novapart

Novapart is a B2B electronic component broker specialising in stock shortages and cost reduction. We source hard-to-find parts and identify compliant alternatives across a catalogue of 420,000+ components from 500+ manufacturers.

Learn more →

Stock Shortage Specialist

When a component is unavailable, discontinued or has an unacceptable lead time, we tap into our network of vetted European and Asian distributors to source what you need — without compromising on quality or traceability.

Request a quote →

Compliant Alternatives

We identify pin-to-pin, electrically equivalent substitutes that meet the same certifications (RoHS, AEC-Q100, REACH) as your original specification — validated against datasheets, not just part numbers. Often at a lower cost.

BOM Analysis service →
